JC-MNP Series

HDPE / PP Monofilament Line

JC-MNP series monofilament extrusion line designed with single-stage-drawing and heat setting. The line is specially conceived to process polypropylene (PP) and high density polyethylene (HDPE).

Technical Data

MODEL Applicable Material Screw Diameter Filament Dia. Range Extrusion Capacity
JC-MNP55   Ø 55 mm 0.15 - 0.50 mm 55 kg/hr
JC-MNP65   Ø 65 mm 0.15 - 0.50 mm 80 kg/hr
JC-MNP80 PP / HDPE Ø 80 mm 0.15 - 0.50 mm 125 kg/hr
JC-MNP90   Ø 90 mm 0.40 - 1.00 mm 180 kg/hr
JC-MNP100   Ø100 mm 0.40 - 1.00 mm 240 kg/hr

Application

Ropes
Awning Cloth
Agriculture / Horticuture Nettings
Safety / Fence Netting
Brush / Broom
Grass Cutting
Other Industrial Purpose
