Handle

JC-LH Series

LDPE / LLDPE Blown Film Line

JC-LH Series Blown Film Extrusion Line is designed for LDPE / LLDPE film production to achieve high output capacity with excellent film quality and transparency, fulfill the requirement for various applications.

Technical Data

MODEL Applicable Material Film Layflat Width Film Thickness Extrusion Capacity Screw Diameter
JC-LH55   1000 mm 0.008 - 0.8 mm 120 kg/hr Ø 55 mm
JC-LH65   1300 mm 0.008 - 0.8 mm 160 kg/hr Ø 65 mm
JC-LH75 LDPE/LLDPE 1600 mm 0.008 - 0.8 mm 220 kg/hr Ø 75 mm
JC-LH85   2000 mm 0.008 - 0.8 mm 300 kg/hr Ø 85 mm
JC-LH100   2500 mm 0.008 - 0.8 mm 380 kg/hr Ø 100 mm
JC-LH120   3000 mm 0.008 - 0.8 mm 450 kg/hr Ø 120 mm

Your Innovative Extrusioneers

your competent partner for plastic extrusion machinery.
